Metered rack Power Distribution Units (PDUs) provide real-time remote monitoring of connected loads. User-defined alarms warn of potential circuit overloads before critical IT failures occur.
- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Metered Rack
- Product Type
- PDU
- Warranty
- Limited Warranty
- 2 Year
- Additional Warranty Information
- 2 years repair or replace
- Technical Information
- PDU Type
- Metered
- Plug/Connector Type
- NEMA L6-30P
- Plug/Connector Detail
- 1
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 12 x IEC 60320 C13
- 4 x IEC 60320 C19
- Power Description
- Input Voltage
- 200 V
- 208 V
- 230 V
- Output Voltage
- 208 V AC
- Input Current
- 30 A
- Physical Characteristics
- Mount Type
- Rack-mountable
- Rack Height
- 2U
- Cord Length
- 12 ft
- Height
- 3.5"
- Width
- 17.5"
- Depth
- 4.4"
- Weight (Approximate)
- 7.41 lb
- Miscellaneous
- Package Contents
- Rack PDU, Metered, 2U, 30A, 208V, (12) C13s & (4) C19
- Cord retention bracket(s)
- Installation guide
- Rack mounting brackets
- User manual
- Certifications & Standards
- cUL Listed|CSA|PSE|UL Listed
- Green Premium
- Yes
- Optimized Energy Efficiency
- Yes
- Product Take Back Program
- Yes
- REACH free of SVHC
- No
- Mercury Free
- Yes
- Lead Free
- Yes
- RoHS Exemption Information
- https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP7811B_ROHS_DECLARATION&p_FileName=AP7811BKIT_ROHS_DECLARATION_US.pdf
- REACH Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=458562847&lang=en-us
- EU RoHS Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=458562847&lang=en-us
- Environmental Profile Availability
- https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1712014_EN
- End of Life Manual Availability
- https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1712014_EN
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
